Product Description
CR225 smart converter RS232/422/485 <> CAN BUS
| Model | CR225 |
| CAN channels | 1 channel |
| CAN baud rate | 10k-1Mbps |
| Serial ports | RS232/485/422 software selection |
| Baud rate of serial ports | 2400-921600bps |
| Configured interface | RS232 |
| Data reception capability | 1200 frames/second |
| Data transmission | 1200 frames/second |
| Interface card format conversion | Supported |
| Transparent conversion | Supported |
| Transparent mark-borne conversion | Supported |
| 120ohm terminal resistor | External |
| ESD | ±8KV |
| Operating temperature | -40°C ~ 85°C |
| Supply voltage | DC 9-36V |
| Material | Metal housing |
| Dimension | 104mm*75.5mm*24.5mm |
| Model | CR225 |
| CAN channels | 1 channel |
| CAN baud rate | 10k-1Mbps |
| Serial ports | RS232/485/422 software selection |
| Baud rate of serial ports | 2400-921600bps |
| Configured interface | RS232 |
| Data reception capability | 1200 frames/second |
| Data transmission | 1200 frames/second |
| Interface card format conversion | Supported |
| Transparent conversion | Supported |
| Transparent mark-borne conversion | Supported |
| 120ohm terminal resistor | External |
| ESD | ±8KV |
| Operating temperature | -40°C ~ 85°C |
| Supply voltage | DC 9-36V |
| Material | Metal housing |
| Dimension | 104mm*75.5mm*24.5mm |
