Product Description
SHARK S8X PLUS-8CH SDI/ HDMI Video Switcher
Product Videos
Custom Field
Display 17.3-Inch FHD IPS Display
Inputs 8×3G-SDI and 2×4K HDMI, 1×BNC REF, 1×AUX (internal interface)
Outputs 2×HDMI(A/B) PGM (configurable), 4×SDI(A/B) PGM (configurable), 1×HDMI MV (source configurable), 1×REF output
Mixer 8×input video embedded audio & 2×XLR/TRS balanced & 3.5mm stereo input; 3.5mm stereo & XLR balanced output
Streaming RTMP(S)/SRT/RTSP/NDI(Optional)
Recording and Playback USB flash drive/SD card/2.5-inch SATA
Features Chroma key, luma key, custom position and size PIP×3, POP, DSK, LOGO overlay, 8-channel PTZ control, transition effects, multi-view source routing, etc.
